DO14K

14K Deck Over

Most popular trailer in it's class in North America.

The 14K Deck Over is a heavy-duty yet lightweight trailer ideal for hauling loads requiring a wider deck. Constructed of fuel-efficient, low-maintenance aluminum, the 14K Deck Over flatbed is engineered to perform and built to last. It's easy to customize your trailer for your specific needs with a wide variety of popular options including upgraded 8k axles, fold-flat ramps, lockable tool box, spare tire, winch and more!

Gallery specs Resources Inventory Buy an EBY

get quick & Easy financing

Gallery

Available Sizes

MODEL

(A) x (B)

CAPACITY*

(C) 66" Wall
(D) 10'5"
Overall Height

CAPACITY*

(C) 72" Wall
(D) 10'11"
Overall Height

CAPACITY*

(C) 78" Wall
(D) 11'5"
Overall Height

CAPACITY*

(C) 84" Wall
(D) 11'11"
Overall Height

CAPACITY*

(C) 96" Wall
(D) 12'11"
Overall Height

(E)
Ground
Clearance

Trap Door Openings

34'6" x 96" Field

N/A

1392 cu ft

N/A

N/A

N/A

24"

24"W x 27"L

40' x 96" Field

1436 cu ft

1579 cu ft

N/A

N/A

N/A

24"

24"W x 27"L

40' x 96" Mid Clearance

1533 cu ft

1676 cu ft

1818 cu ft

1961 cu ft

2246 cu ft

20.75"

32.25"W x 43.5"L

40' x 96" Commercial

1536 cu ft

1679 cu ft

1821 cu ft

1964 cu ft

2249 cu ft

18"

26.25"W x 35.5"L

40' x 102" Field

1534 cu ft

1686 cu ft

N/A

N/A

N/A

24"

30"W x 27"L

40' x 102" Commercial

1642 cu ft

1794 cu ft

1946 cu ft

2098 cu ft

2402 cu ft

18"

32.25"W x 35.5"L

42'3" x 96" Field

1498 cu ft

1650 cu ft

N/A

N/A

N/A

24"

24"W x 27"L

42'3" x 96" Mid Clearance

1621 cu ft

1772 cu ft

1923 cu ft

2074 cu ft

2346 cu ft

20.75"

32.25"W x 43.5"L

42'3" x 96" Commercial

1624 cu ft

1775 cu fl

1926 cu ft

2077 cu ft

2376 cu ft

18"

26.25"W x 35.5"L

42'3" x 96" Commercial, XL

N/A

N/A

2012 cu ft

2163 cu ft

2379 cu ft

18"

32.25"W x 53.25"L

42'3" x 102" Field

1600 cu ft

1761 cu ft

N/A

N/A

N/A

24"

30"W x 27"L

42'3" x 102" Commercial

1735 cu ft

1896 cu ft

2057 cu ft

2219 cu ft

2541 cuft

18"

32.25"W x 35.5"L

42'3" x 102" Commercial, XL

N/A

N/A

2151 cu ft

2312 cu ft

2634 cu ft

18"

32.25"W x 53.25"L

49'11" x 96" Field

N/A

1766 cu ft

1932 cu ft

N/A

N/A

24"

24"W x 34"L

49'11" x 96" Mid Clearance

N/A

1865 cu ft

2028 cu f

2195 cu ft

N/A

20.75"

32.25"W x 43.5"L

49'11" x 96" Commercial

N/A

1868 cu ft

2031 cu ft

2198 cu ft

N/A

18"

32.25"W x 35.5"L

49'11" x 96" Commercial, XL

N/A

N/A

2087 cu ft

2254 cu ft

N/A

18"

32.25"W x 53.25"L

49'11" x 102" Commercial

N/A

1995 cu ft

2170 cu ft

2348 cu ft

N/A

18"

32.25"W x 35.5"L

49'11" x 102" Commercial, XL

N/A

N/A

2220 cu ft

2404 cu ft

N/A

18"

32.25"W x 53.25"L

Specifications

18'6", 20' and 24'6" lengths (Custom lengths up to 24'6" available)
Deck Width: 97-3/4" (102" overall)
Payload Capacity: 18'6" - 11,570 lbs; 20' - 11,460 lbs; 24'6" - 11,230 lbs
Upgraded 8k axles available with electric brakes for 16,000 LB GVWR towing capacity
Custom GVWR available

A

B

B

Description

Overall Length

Inside Length (w/ barn doors)

Inside Length (w/ 2-way spreader gate)

Load Capacity

Empty Weight

DO14K18

23'4-3/4"

18'6"

13'9"

11,570 lbs

2,430 lbs

DO14K20

24'10-3/4"

20'

15'9"

11,460 lbs

2,540 lbs

A

B

C

Description

Full Trailer Length

Deck Length

Nose Length

DO14K18

23'4-3/4"

18'6"

13'9"

DO14K20

24'10-3/4"

20'

15'9"

DO14K25

29'4-3/4"

24'6"

20'3"

A

B

C

Description

Overall Length

Full Deck Length

Flat Deck Length

Load Capacity

Empty Weight

DO14K18

23'4-3/4"

18'6"

13'9"

11,570 lbs

2,430 lbs

DO14K20

24'10-3/4"

20'

15'9"

11,460 lbs

2,540 lbs

DO14K25

29'4-3/4"

24'6"

20'3"

11,230 lbs

2,770 lbs

*16K GVWR models with optional 8K axles and 17.5" wheels.

*16K GVWR models with optional 8K axles and 17.5" wheels.

A

B

C

Description

Overall Length

Full Deck Length

Flat Deck Length

Load Capacity

Empty Weight

LP16K18*

23’4-3/4”

18’6"

15’9”

13,450 lbs

2,550 lbs

LP16K20*

24’10-3/4”

20’

17’9”

13,360 lbs

2,640 lbs

LP16K25*

29’4-3/4”

24’6”

22’3”

13,260 lbs

2,740 lbs

A

B

C

Description

Overall Length

Full Deck Length

Flat Deck Length

Load Capacity

Empty Weight

DO16K18*

23’4-3/4”

18’6"

13’9”

13,240 lbs

2,760 lbs

DO16K20*

24’10-3/4”

20’

15’9”

13,130 lbs

2,870 lbs

DO16K25*

29’4-3/4”

24’6”

20’3”

13,000 lbs

3,000 lbs

*16K GVWR models with optional 8K axles and 17.5" wheels.

*16K GVWR models with optional 8K axles and 17.5" wheels.

Standard Features

Heavy duty features built in standard.

Popular Options

Make it exactly what you need with these popular options.

POPULAR OPTIONS

Accessory Packages

Charter, Founder, Signature

Power Tarp

Shur-Co 4500 Tarp System

Power Doors

Shur-Co Power Door Openers

Fenders

Minimizer Fenders

Side Panel Color

White, Black, Gun Metal Gray

Side Lights

(2) rows of (9), (2) rows of (17)

Rear Lights

Automatic back-up lights

Stainless

Front Panel, Rear Panel, Corners

Vibrators

Permanent and removable

Mudflaps

3/4" Flaps with stainless weights

Lift Axle

Auto deploy front or rear lift

Tires

General / Continental

Packages

DESCRIPTION

CHARTER

CHARTER PLUS

FOUNDER

SIGNATURE

Stainless steel front panel

•

Stainless steel rear header w/ painted rear panel

•

•

Stainless steel rear panel

•

•

Stainless steel corners

•

•

•

•

Polished corner caps

•

Side marker lights

2 rows of 5

2 rows of 5

2 rows of 9

2 rows of 17

(4) Additional rear side marker lights

•

(7) Dual-function rear header lights

•

•

•

•

(3) Additional 1" buckplate lights

•

(3) Additional taillights on buckplate

•

Automatic backup lights

•

Trap lights between the tubs

•

•

•

Duraframe aluminum suspension frame

•

•

•

•

Galvanized upper coupler

•

•

•

•

Galvanized suspension brackets

•

•

•

•

Shur-Co power tarp system

Smart 3

Smart 3

Smart 3

Smart 2

Alcoa LVL inner wheels

•

•

Alcoa LVL outer wheels

•

•

•

Durabrite outer wheels

•

Tires

General

General

General

Continental

Black poly fenders

•

•

Poly chrome fenders

•

Stainless steel hubcaps and lug nut covers

•

•

•

•

pdf resources

Equipment Trailer Owner's Guide

14K Deck Over Dimensions

14K Deck Over Brochure

10k Deck Over Brochure
